If you are experiencing a Scania truck articulation control system ACS 10 end position sensor error, follow these instructions to resolve the issue.
Related Contents:
2024.04 Scania SDP3 V2.60.1 V2.40 Diagnostic Software Free Download
Scania VCI3 Diagnostic Adapter Full Chips
Scania SDP3 2.60.1.7 2024 latest software version
1. Error Identification:
When the end position sensor is activated despite the vehicle speed being high enough for the articulation unit to be relatively straight, it indicates a fault in the system.
2. Possible Causes:
There are a few potential reasons for this error:
– Defective end position sensor: The sensor may be malfunctioning and not providing accurate readings.
– Short circuit or open circuit: There could be a wiring issue with the end position sensor circuit, such as a short or an open circuit.
– Deformed or misaligned plate: The plate that activates the end position sensor may be deformed or moved out of its correct position.
3. Notes:
When this error occurs, the ACS warning indication will be displayed, and the truck may enter limp home mode as a safety measure.
4. Action Steps:
To troubleshoot and resolve the end position sensor error, follow these steps:
– First, check the end position sensor itself for any signs of damage or malfunction. If necessary, replace the sensor with a new one.
– Inspect the cable harnesses, including the harness-to-harness and harness-to-component connectors, for any loose connections or damage. Repair or replace any faulty components.
– Verify the position of the plate that activates the end position sensor. Make sure it is not deformed or misaligned. If needed, adjust or replace the plate to ensure proper functioning.
By following these steps, you should be able to diagnose and fix the Scania truck ACS 10 end position sensor error. Remember to take necessary safety precautions and consult a professional if needed.
